PRODUCT SPECIFICATIONS
| Li-ion Battery | Talk PRO H350B | Modulation limit | ≤ 5KHz / 2.5KHz |
| Frequency range | VHF: 136~174MHz UHF: 350~390MHz; 400~470MHz | FM distrotion | ≤ 5% |
| Channel capacity | 16(15+S) | Residual FM | -45dB / -40dB |
| Channel spacing | 25.0KHz/ 12.5KHz | Adjacent channel power | -70dB / -60dB |
| Operating temperature | -25~+55°C | Spurious and Harmonics | ≤- 36dBm |
| Antenna impedance | 50 ohms | Sensitivity | 0.22μV / 0.25μV |
| Operating voltage | 7.4V | Adjacent channel selectivity | 70dB / 60dB |
| Weight | 220g (with antenna & battery） | Intermodulation reject ratio | 65dB |
| Dimension | 98x60x34mm (H x W x D) | Spurious response reject ratio | 70dB |
| Battery | 2600mAh (Li-ion Battery) | S/N | 45dB / 40dB |
| RF power（H/L） | UHF: 4W/1W VHF: 5W/1W | Rated audio power output | 0.8W |
| Modulation type | 16K F3E / 8K F3E | Rated audio distortion | ≤5% |
